TPU Layflat Hose Quote Checklist
TPU Layflat Hose is requested for industrial transfer projects, temporary lines and site supply applications. Please send inner diameter, roll length, working condition, coupling request, quantity, application medium, packing method and destination for quotation support.
Related purchasing paths: Industrial Conveying Solutions category, High Pressure TPU Layflat Hose, Conveyor Belt Cleaner, and contact OKAY Plastics.
Products Description
TPU layflat hose is a flat hose made from thermoplastic polyurethane (TPU) material. The hose's braided layer is made from high-strength polyester filament. The inner and outer rubber layers are formed in a single extrusion process using polyurethane material. It features wear resistance, acid and alkali resistance, oil resistance, corrosion resistance, and ageing resistance. TPU flat flexible hose is suitable for industries such as petroleum transportation, coal mine emergency drainage, urban emergency drainage, agricultural water supply and irrigation, industrial wastewater transportation, and firefighting long-distance water supply.
If you would like to learn more about the product details or are interested in purchasing, please feel free to contact us!
Product parameters
Product Application
Product Features
UV Resistance: Under 2x magnification, the outer rubber layer of the hose shows no cracks.
Abrasion Resistance: Using an H-22 abrasive wheel with no additional pressure applied, the number of wheel revolutions before the reinforcement layer is exposed shall be no less than 250,000.
Scratch Resistance: For hoses used in ship-to-ship or shore-to-ship oil and water transfer, the tool must complete at least 7,000 cycles before leakage occurs due to surface scratching.
Anti-Static Performance: Oil transfer hoses are reinforced with continuously conductive anti-static wires. These conductive wires ensure electrical continuity between both hose ends, with a maximum resistance not exceeding 50 Ω/s. The hose maintains conductivity even when coiled, bent, or subjected to internal pressure as specified in standards.
Oil Contamination Resistance: When used to transport oil products that require control over colloid content, the test liquid after filling must remain clear and transparent, free from suspended solids or other impurities. After testing, the detergent colloid content in the test liquid shall not exceed 6 mg/100 ml.
Hydraulic Performance: The hose must meet the specified test pressure and minimum burst pressure. Under test pressure, there should be no leakage or visible deformation. During burst testing, the hose should rupture longitudinally. Under the rated working pressure, the change in hose length shall not exceed 2%, and the diameter expansion rate shall not exceed 7%. When observed in the direction of fluid flow, the hose should not twist counterclockwise.
Water and Pollution Resistance: Complies with the safety evaluation standards specified in GB/T 17219.
Company Profile
Henan Okay Plastic Industry Co., Ltd. has a professional design team, can be processed by samples and customised by drawings, and can design drawings according to your needs to meet the customized needs of customers. The company mainly produces anti-skid paving slabs, simulation skateboards, ultra-high molecular weight polyethylene sheet liners, plastic rollers, polyethylene anvil plates, shaped parts, outrigger pads.
Prepare a faster TPU layflat hose quotation
For project review, please include: hose diameter, length, pressure requirement, conveyed medium, connector type, operating condition, quantity and destination country. These details help confirm material suitability, processing needs and quote requirements.
TPU Layflat Hose FAQ
What information is needed for TPU layflat hose quotation?
Please provide hose diameter, pressure requirement, roll length, quantity, fluid type, coupling requirement, working environment and destination.
Can TPU layflat hose be supplied with couplings?
Coupling type, clamp requirement, cut length, roll packing and label needs can be reviewed when project details are available.
What should buyers confirm before ordering?
Diameter, pressure, length, fluid type, temperature range, application, quantity, packing method and delivery schedule should be confirmed.
Related pages: high pressure TPU layflat hose, industrial conveying solutions and anti spillage skirt board.
TPU Layflat Hose Supplier Quote Notes
What information helps quote TPU layflat hose?
Please provide hose diameter, working pressure, hose length, color, coupling request, fluid or material handled, working environment, quantity and destination.
Which TPU layflat hose projects can be reviewed?
TPU layflat hose can be reviewed for mine dewatering, irrigation transfer, slurry movement, temporary water discharge, construction drainage and industrial fluid transfer.
How can a supplier check the hose requirement?
Site photos, pump information, route length, bend condition, abrasion condition, connection method, packing request and shipping destination help prepare quotation details.
Related product routes: high pressure TPU layflat hose, TPU layflat hose and UHMWPE conveyor belt roller.
